Explore 77+ IEC 60529 ingress protection codes, compare ratings side-by-side, and find the exact specification your project needs with our intelligent selection wizard.
Solid 6
Dust-Tight
Liquid 7
Temporary Immersion (up to 1 m)
The IP rating comparisons engineers search for most — with instant side-by-side answers.
Every solid-protection level (rows, 0–6) against every liquid-protection level (columns, 0–9K). Click any documented cell to open its full specification.
| Solid \ Liquid / | 0No Protection | 1Vertically Dripping Water | 2Dripping Water at 15° Tilt | 3Spraying Water | 4Splashing Water | 5Water Jets | 6Powerful Water Jets | 7Temporary Immersion | 8Continuous Immersion | 9KHigh-Pressure, High-Temp Water Jets |
|---|---|---|---|---|---|---|---|---|---|---|
0No Protection | ||||||||||
1> 50 mm | ||||||||||
2> 12.5 mm | ||||||||||
3> 2.5 mm | ||||||||||
4> 1 mm | ||||||||||
5Dust-Protected | ||||||||||
6Dust-Tight |
Read each cell as IP<solid><liquid> — the row digit is solid-object protection, the column digit is water protection. A dot (·) marks a valid but uncommon combination not covered with a dedicated page.
Start with the most-searched ingress protection codes, or browse the full database.
IP65 is dust-tight and resists low-pressure water jets (6.3 mm nozzle, 30 kPa). It is the most common standard for fully exposed outdoor electronics such as lighting, cameras, and EV chargers.
IP66 is dust-tight and resists powerful water jets (12.5 mm nozzle, 100 kPa). A robust outdoor rating for equipment exposed to heavy rain, storms, or directed high-pressure hosing (but not high-pressure washdown).
IP67 is dust-tight and withstands temporary immersion in water up to 1 meter for 30 minutes. The go-to rating for outdoor and rugged devices that may be briefly submerged.
IP68 is dust-tight and protects against continuous immersion in water under conditions specified by the manufacturer (typically deeper than 1 meter for prolonged periods). The standard for submersible and marine equipment.
IP69K is dust-tight and resists high-pressure (8–10 MPa), high-temperature (80 °C) water jets. The highest IP rating, required for food, beverage, and pharmaceutical washdown environments.
IP54 is dust-protected (limited ingress, no harmful deposit) and resists splashing water from any direction. A versatile rating for industrial and outdoor-covered equipment in dusty, damp environments.
IP44 protects against small solid objects (1 mm) and splashing water from any direction. It is the common minimum rating for outdoor-covered fixtures and bathroom zone equipment.
IP55 is dust-protected and resists low-pressure water jets (6.3 mm nozzle, 30 kPa). A popular industrial rating for equipment exposed to dust and directed water spray but not immersion.
Answer three quick questions about your environment and exposure, and our wizard recommends the exact IEC 60529 code for your project — or compare two ratings head-to-head.
Each environment demands different protection. Browse curated rating recommendations for 8 key industries.
Every term you need to read an IP rating — from “dust-tight” to “oscillating tube”.
In-depth guides on IP ratings, testing, and specification best practices.
Decode, compare, convert, and select IP ratings with our suite of interactive engineering tools.
Clear answers to the most common questions about IP ratings and IEC 60529.
Each rating page includes its own detailed FAQ. Find your code to see targeted answers.
